| Module Type | TC63-18 | TC73-21 | TC64-24 | ||||||
| Product Dimensions(L*W*H/mm) | 6000×3000×2800 | 7000×3000×2800 | 6000×4000×3000 | ||||||
| Max.Outside Area(m²) | 18 | 21 | 24 | ||||||
| Max.Inside Area(m²) | 16.2 | 19.0 | 22.0 | ||||||
| House Weight(Kgs) | 1200 | 1350 | 1500 | ||||||
| Description of House Materials | Same as container house | ||||||||
| Description of Windows &Doors | Can be customized | ||||||||
| Max.Solar Panel on Roof (W) | 3690 | 4920 | |||||||
| Max.Solar Tile on Roof (W) | 3240 | 3780 | 5320 | ||||||
| Type of Inverter | Off-grid type(with AC back-up) | ||||||||
| Power of Inverter(kW) | 3~6(one phase) | ||||||||
| Type of Battery | Lithium battery(LiFePO4) | ||||||||
| Capacity of Battery(kWh) | 3~20 | ||||||||
| Type of Water Heater | PVT | ||||||||
| Volume of Water Tank (L) | 150~250 | ||||||||
| Intelligent Housing Systems | Can be customized and configured | ||||||||
| Other Furniture | Can be customized and configured | ||||||||
| Colors Available | Standard White Grey, Customized Red, Blue, Green, Camouflage, etc | ||||||||
| Mechanical Properties | |||||||||
| Warranty(Years) | 2 | ||||||||
| Life Span(Years) | ≥10 | ||||||||
| Packing Configuration | |||||||||
| Container Loading Qty (20GP) | 7 | 0 | 7 | ||||||
| Container Loading Qty (40HQ) | 15 | 13 | 14 | ||||||
| Basic Properties | |||||||
| Module Type | CH33-09 | CH63-18 | CH73-21 | CH64-24 | |||
| Product Dimensions(L*W*H/mm) | 3000×3000×2800 | 6000×3000×2800 | 7000×3000×2800 | 6000×4000×3000 | |||
| Max.Outside Area(m²) | 9 | 18 | 21 | 24 | |||
| Max.Inside Area(m²) | 7.8 | 16.2 | 19.0 | 22.0 | |||
| Max.Outside Volume(m³) | 25.2 | 50.4 | 58.8 | 72 | |||
| Max.Inside Volume(m³) | 20.2 | 42.1 | 49.4 | 61.6 | |||
| Weight(Kgs) | 900 | 1200 | 1350 | 1500 | |||
| Description of Doors | 2035*950mm/Painting steel with Bar Lock | ||||||
| Description of Windows | 1100*925mm/Double Galasses POM with Security Fence | ||||||
| Description of Frames | 2.3mm Stoving varnish steel | ||||||
| Description of Wall Panels | 50/75mm Rock Wool Sanwish Panel | ||||||
| Description of Floors | 16-18mm Fireproofing MgO Board | ||||||
| Description of Rooftiles | 0.24-0.45mm Painting Steel | ||||||
| Standard Configuration-Doors | 1 | 1 | |||||
| Standard Configuration-Windows | 1 | 2 | |||||
| Colors Available | Standard White Grey, Customized Red, Blue, Green, Camouflage, etc. | ||||||
| Mechanical Properties | |||||||
| Floor Lve Load (KN/m²) | 2 | ||||||
| Roof Live Load (KN/m²) | 1 | ||||||
| Wind Load(KN/m²) | 0.6 | ||||||
| Aseismatic Level | 8 | ||||||
| Fire-proofing Class | A | ||||||
| Warranty (Years) | 2 | ||||||
| Life Span(Years) | >10 | ||||||
| Packing Configuration | |||||||
| Packing Way | Bulk parts without pallets | ||||||
| Container Loading Qty(20GP) | 12 | 7 | 0 | 7 | |||
| Container Loading Qty(40HQ) | 25 | 15 | 13 | 14 | |||
