Solar Power Container for Mining Industry, Oil and Gas Exploration

Total Weight (Tons)：5
Type of Container：8GPF x1
Solar Array Capacity (Pmax /kWp)：22.68(20~25)
Type of Solar Module (W)：630 x36(550~650)
String Inverter (kW)：20 x1
Bracket (Number of Module per Sheet)：1 x36
Total Unfolded Footprint (L*W*H/m)：56*2.3(2.9)*0.6(2.2)
Occupied Area of Whole System (m²)：126(56*2.25)
Complete Unfolding Time (mins)：60
Complete Folding Time (mins)：50
Installation Persons：4

Total Weight (Tons)：8
Type of Container：10GPF x1
Solar Array Capacity (Pmax /kWp)：40.32(40~45)
Type of Solar Module (W)：480 x84(480~520)
String Inverter (kW)：40 x1
Bracket (Number of Module per Sheet)：2x42
Total Unfolded Footprint (L*W*H/m)：89*2.4(3.0)*0.8(2.6)
Occupied Area of Whole System (m²)：212(89*2.38)
Complete Unfolding Time (mins)：80
Complete Folding Time (mins)：60
Installation Persons：4

Total Weight (Tons)：13
Type of Container：20GP x1
Solar Array Capacity (Pmax /kWp)：80.64(80~90)
Type of Solar Module (W)：480 x168(480~520)
String Inverter (kW)：80 x1
Bracket (Number of Module per Sheet)：4x42
Total Unfolded Footprint (L*W*H/m)：89*4.7(6.0)*0.8(2.6)
Occupied Area of Whole System (m²)：421(89*4.73)
Complete Unfolding Time (mins)：120
Complete Folding Time (mins)：80
Installation Persons：4

Total Weight (Tons)：16
Type of Container：20HQx1
Solar Array Capacity (Pmax /kWp)：99.96(100~110)
Type of Solar Module (W)：595×168(585~650)
String Inverter (kW)：100 x1
Bracket (Number of Module per Sheet)：4x42
Total Unfolded Footprint (L*W*H/m)：104*4.7(6.0)*0.9(2.9)
Occupied Area of Whole System (m²)：492(104*4.73)
Complete Unfolding Time (mins)：150
Complete Folding Time (mins)：100
Installation Persons：4

Total Weight (Tons)：27
Type of Container：40HQx1
Solar Array Capacity (Pmax /kWp)：161.28(160~180)
Type of Solar Module (W)：480x336(480~520)
String Inverter (kW)：80x2
Bracket (Number of Module per Sheet)：4x84
Total Unfolded Footprint (L*W*H/m)：89*10.5(12.0)*0.8(2.9)
Occupied Area of Whole System (m²)：935(89*10.5)
Complete Unfolding Time (mins)：180
Complete Folding Time (mins)：120
Installation Persons：6
